Lightweight Carbon Road Rim Brake Classic Frame

Lightweight Carbon Road Rim Brake Classic Frame

Lightweight Carbon Road Rim Brake Classic Frame is constructed from Toray T700&T800.This Classic Carbon Framest includes fork,seatpost,hanger and cable cover.

  • Item NO.:

    FM-R879
  • Order(MOQ):

    10
  • Payment:

    Paypal, Bank Transfer, West Union
  • Product Origin:

    Xiamen,China
  • Color:

    UD Matte/Glossy/painting
  • Product Detail

Lightweight Carbon Road Rim Brake Classic Frame


Product Feature

  • Super lightweight, frame constructed with premium Toray T800 carbon fiber, best strength to weight ratio with no expense spared.
  • This classic carbon frame inclueds  fork,seatpost,hanger and cable cover .
  • 480mm、500mm、520mm are available.


Specification

Model:
FM-R879
Name:
carbon fiber bicycle frame
Size:
480/500/520 mm
BB:
BB86 system
Test:
All parts passed EN14781 CYCLEUROPE
Headset:
1-1/8" , 1-3/8" ( top 41.8mm, bottom 46.9mm)
Finish:
UD matt or glossy
Weight:
1250g ± 50g (frame+seatpost)
Fork Weight:
340g±10g
Groupset:
Group fit for electronic group and mechanical group at the same time
Including:
Frameset include fork,seatpost,hanger and cable cover


Product Geometry

SIZE A B C D E F G H I J K FC WB
480 480mm 428 514 374 100 496 70.9 741 70 74.3° 405 579 973
500 500mm 448 526 379 118 514 71.2 759 70 74° 405
587 975

520

520mm 468 540 384 136 532 71.4 776 70 73.7° 405
596 991
540 540mm 488 553 389 148 548 72.7 796 70 73.4° 405
594 989
560 560mm 508 564 394 166 566 72.9 815 70 73.1° 405
603 998



Read More For Production Of Carbon Frames By Top-Fire Factory


Read More For Testing Of Carbon Frames By Top-Fire Factory
