700C V-Shape Full Carbon Tubular 25mm Width Road Rim

700C V-Shape Full Carbon Tubular 25mm Width Road Rim

700C V-Shape Full Carbon 25mm Width Road Rim is constructed from Toray T700&T800.It is the 25mm light weight rim with 30mm、35mm、38mm、45mm、50mm、55mm、60mm、88mm depth.

  • Item NO.:

    RT30S
  • Payment:

    Paypal, Bank Transfer, West Union
  • Product Origin:

    Xiamen,China
  • Color:

    UD/3K(Customized Painting Acceptable)
  • Product Detail

700C V-Shape Full Carbon Tubular 25mm Width Road Rim


Product Feature

  • Super lightweight, rim constructed with premium Toray T700 & T800 carbon fiber, best strength to weight ratio with no expense spared.
  • This light weight rims with 25mm width V-shape makes road tubular rims lightweight but still stiff, keeping them stable in cross winds condition.
  • Carbon Strip Reinforcement. Use unique carbon strip to strengthen the spoke tension and stabilize rim structure and reduce the rim weight.
  • Smooth Wall Tec. No folded prepreg during curing, smooth both inside and outside rim wall to reduce potential quality issues.


Specification

Model:
RT30S RT35S RT38S RT45S RT50S RT55S RT60S RT88S
SIZE:
700C 700C
700C
700C
700C
700C
700C
700C
Weight:
330±15g
345±15g
355±15g
380±15g
390±15g
445±15g
455±15g
520±20g
weight(light): 285±15g
300±10g
305±15g
335±15g
350±15g
405±15g
420±15g
480±15g
Braking  System:
Rim Brake
Rim Brake
Rim Brake
Rim Brake
Rim Brake
Rim Brake
Rim Brake
Rim Brake
Applicable Bicycle:
Road Bicycles
Road Bicycles
Road Bicycles
Road Bicycles
Road Bicycles
Road Bicycles
Road Bicycles
Road Bicycles
Appearance:
UD/3K/12K
UD/3K/12K
UD/3K/12K
UD/3K/12K
UD/3K/12K
UD/3K/12K
UD/3K/12K
UD/3K/12K
Finishing:
Matte/Glossy
Matte/Glossy
Matte/Glossy
Matte/Glossy
Matte/Glossy
Matte/Glossy
Matte/Glossy
Matte/Glossy
Material:
Full carbon fiber (Toray T700&T800)
Full carbon fiber (Toray T700&T800)
Full carbon fiber (Toray T700&T800)
Full carbon fiber (Toray T700&T800)
Full carbon fiber (Toray T700&T800)
Full carbon fiber (Toray T700&T800)
Full carbon fiber (Toray T700&T800)
Full carbon fiber (Toray T700&T800)
Spoke Hole:
16H-36H
16H-36H
16H-36H
16H-36H
16H-36H
16H-36H
16H-36H
16H-36H
Outer width:
25mm 25mm
25mm
25mm
25mm
25mm
25mm
25mm
Depth:
30mm 35mm 38mm 45mm 50mm 55mm 60mm 88mm
ERD:
583mm 573mm
567mm
553mm
543mm
533mm
523mm
469mm
Type:
Tubular
Tubular
Tubular
Tubular
Tubular
Tubular
Tubular
Tubular
Geometry:








Standard:
En Standard
En Standard
En Standard
En Standard
En Standard
En Standard
En Standard
En Standard
Assembly Hole Dia:
8.5mm
8.5mm
8.5mm
8.5mm
8.5mm
8.5mm
8.5mm
8.5mm
Spoke Hole Dia:
4.5mm
4.5mm
4.5mm
4.5mm
4.5mm
4.5mm
4.5mm
4.5mm
Valve Hole Dia:
6.5mm
6.5mm
6.5mm
6.5mm
6.5mm
6.5mm
6.5mm
6.5mm
Roundess:
<0.25mm
<0.25mm
<0.25mm
<0.25mm
<0.25mm
<0.25mm
<0.25mm
<0.25mm
Flatness:
<0.15mm <0.15mm
<0.15mm
<0.15mm
<0.15mm
<0.15mm
<0.15mm
<0.15mm
Max Spoke Tension:
>350kgf
>350kgf
>350kgf
>350kgf
>350kgf
>350kgf
>350kgf
>350kgf
Weight limit:
<110kg
<110kg
<110kg
<110kg
<110kg
<110kg
<110kg
<110kg


Read More For Production Of Carbon Rims By Top-Fire Factory


Read More For Testing Of Carbon Rims By Top-Fire Factory
