Carbon Cyclocross Disc Gravel Bike Frame For BB T47

Carbon Cyclocross Disc Gravel Bike Frame For BB T47

Carbon Cyclocross Disc Gravel Bike Frame is constructed from Toray T700&T800.This is a BB T47 gravel bike frame that has passed CEN SGS Test.

  • Item NO.:

    FM-R898HE
  • Order(MOQ):

    10
  • Payment:

    Paypal, Bank Transfer, West Union
  • Product Origin:

    Xiamen,China
  • Color:

    UD Matte/Glossy/painting
  • Product Detail

Carbon Cyclocross Disc Gravel Bike Frame For BB T47


Product Feature

  • This carbon gravel bike frame are tailored for long-distance comfort, with disc brakes, big tyre clearance and geometry honed to excel both on the road and off, whether it's a gravel, forest or dirt track.
  • Both 700c and 650B compatible.
  • Disc brakes allow frame clearances for fatter tyres, making for a bike that can cope with a very wide range of surfaces and that points & laughs at potholes.
  • At the adventure end of the spectrum, these are the rugged successors to traditional long-distance touring bikes.
  • With even the tiniest lanes infested with motor traffic, gravel bikes get you properly away from dangerous drivers.


Specification

Item NO.
FM-R898HE
Type:
700C carbon gravel bike frame
Material:
 100% Carbon Fiber Toray T700 & T800
Weave:
UD Matte/Glossy/painting
Available size:
44/48/50/53/56cm
Headset:
1-1/2''(top)/1-1/2''(down)
Brake:
Flat mount thru axle
Bottom Bracket:
BB T47
Tire size:
700X42C or 27.5X2.1"
Frame Weight:
from 1120g+-30g (M)
Fork Weght:
530+-15g
Seatpost Weight:
245+-15g
Frame rear spacer:
142mmX12mm thru axle
Fork spacer:
100mmX12mm thru axle
Cable routing:
Di2 and Machine compatible
Test: CEN SGS

Teleport To The Fork Page


Product Geometry


Carbon Cyclocross Disc Gravel Bike Frame For BB T47



S O HS SC HC G RC WB FC F OT STACK REACH TRAIL
440 519.7 110 74 70 70 425 1006.0 592.4 397 50 529.3 367.9 72.5
480 534.8 120 73.5 71 70 425 1008.9 593.8 397 50 542.6 374.1 66.5
500 549.7 140 73 71.5 70 425 1014.5 599.4 397 50 563.4 377.5 65.4
550 574.7 175 72.5 72 70 425 1029.6 614.5 397 50 598.6 385.9 60.4
580 594.8 205 72.5 72 70 425 1049.8 634.5 397 50 627.1 397.1 60.4
