Carbon gravel ebike frame with rear hub motor mahle X35 e-bike frame

Carbon gravel ebike frame with rear hub motor mahle X35 e-bike frame

Carbon gravel ebike frame with rear hub motor mahle X35 e-bike frame

  • Item NO.:

    FM-RD23
  • Product Detail

Item No.:
FM-RD23
Material:
 full carbon
Weave:
UD
Include:
Frame and Fork
Headset size:
top 1-1/2 down 1-1/2
BB:
BSA/BB30 /BB T47
Size:
47/50/53/57
Fork clearance:
100mm
Rear clearance:
135mm
Seatpost Inner diameter:
31.6mm
Seatpost outer diameter
34.9mm
Brake Type:
Flat mount Disc Brake
Cables:
full internal (hidden)
Motor:
Rear hub motor mahle X35 or FSA
Battery:  mahle X35 , Mahle X20  FSA battery
Warranty:
2 years

Product Geometry

carbon road ebike frame


Can do your custom logo design painting :


Some completed bike photos
